Descripción de Producto
| El modelo | La potencia del motor | La presión de trabajo | La velocidad | Capacidad nominal | El diámetro del tubo de salida | Dimensiones (mm) | Unidad de peso (Kg) | |||||
| KW | Hp | Bar | Psig | M³/min | El cfm | Longitud | El ancho | Altura | ||||
| DMLV-22G | 22 | 30 | 2.1-3 | 74-106 | 3300 | 1.84-6.46 | 65-228 | DN50 | 1415 | 1030 | 1330 | 1330 |
| DMLV-37G | 37 | 50 | 2.1-3 | 74-106 | 2950 | 2.82-9.74 | 100-344 | DN65 | 2160 | 1400 | 1750 | 1400 |
| DMLV-37G | 37 | 50 | 2.1-3 | 74-106 | 3100 | 3.37-11.55 | 119-408 | DN65 | 1900 | 1200 | 1650 | 1420 |
| DMLV-37G | 37 | 50 | 2.1-3 | 74-106 | 2700 | 3.27-11.23 | 115-397 | 65 | 2160 | 1400 | 1750 | 1470 |
| DMLV-55G | 55 | 75 | 2.1-3 | 74-106 | 2950 | 4.65-15.82 | 164-559 | 80 | 2420 | 1530. | 1750 | 1980 |
| DMLV-55G | 55 | 75 | 2.1-3 | 74-106 | 1480 | 5.06-17.21 | 179-608 | DN80 | 2160 | 1400 | 1750 | 2100 |
| DMLV-55G | 55 | 75 | 2.1-3 | 74-106 | 2700 | 4.64-15.79 | 164-558 | DN80 | 2160 | 1400 | 1750 | 1900 |
| DMLV-75G | 75 | 100 | 2.1-3 | 74-106 | 2100 | 7.16-24.2 | 253-855 | DN80 | 2160 | 1400 | 1750 | 2830 |
| DMLV-75G | 75 | 100 | 2.1-3 | 74-106 | 2980 | 6.04-20.48 | 213-723 | DN80 | 2160 | 1400 | 1750 | 2700 |
| DMLV-90G | 90 | 120 | 2.1-3 | 74-106 | 1480 | 8.9-30.01 | 314-1060 | DN125 | 2900 | 1830 | 2000 | 4000 |
| DMLV-90G | 90 | 120 | 2.1-3 | 74-106 | 2950 | 7.63-25.78 | 269-910 | 125 | 2900 | 1830 | 2000 | 3800. |
| DMLV-90G | 90 | 120 | 2.1-3 | 74-106 | 2970 | 7.16-24.21 | 253-855 | DN125 | 2900 | 1830 | 2000 | 3800. |
| DMLV-110G | 110 | 150 | 2.1-3 | 74-106 | 1800 | 10.85-36.5 | 383-1289 | DN125 | 2900 | 1830 | 2000 | 4600 |
| DMLV-110G | 110 | 150 | 2.1-3 | 74-106 | 2950 | 9.61-32.35 | 339-1142 | DN125 | 2900 | 1830 | 2000 | 4000 |
| DMLV-132G | 132 | 175 | 2.1-3 | 74-106 | 1490 | 14.17-47.57 | 500-1680 | DN150 | 3400 | 2050 | 2250 | 5000 |
| DMLV-132G | 132 | 175 | 2.1-3 | 74-106 | 2700 | 11.26-37.86 | 398-1337 | DN125 | 2900 | 1830 | 2000 | 4800 |
| DMLV-160G | 160 | 215 | 2.1-3 | 74-106 | 2950 | 12.75-42.84 | 450-1513 | DN150 | 3400 | 2050 | 2250 | 4800 |
| DMLV-160G | 160 | 215 | 2.1-3 | 74-106 | 2980 | 12.92-43.4 | 456-1533 | 150 | 3400 | 2050 | 2250 | 5800. |
| DMLV-160G | 160 | 215 | 2.1-3 | 74-106 | 1650 | 15.7-52.67 | 554-1860 | DN200 | 4250 | 2280 | 2550 | 6200 |
| DMLV-185G | 185 | 250 | 2.1-3 | 74-106 | 2000 | 19.05-63.85 | 672-2255 | DN200 | 4250 | 2280 | 2550 | 7000 |
| DMLV-200G | 200 | 270 | 2.1-3 | 74-106 | 2300 | 20.97-70.23 | 741-2480 | DN200 | 4250 | 2280 | 2550 | 8000 |
